For a homeowner with a house to spray, yes. At about $379 it turns a two-to-three-day brush-and-roll exterior into an afternoon, sprays unthinned latex at 3000 psi, takes a 0.017-inch tip for heavy exterior coatings, and runs up to 100 feet of hose off a cart you roll instead of carry. It is not worth it if you spray for money — the 125-gallon-a-year duty rating is real — or if the whole job is one kitchen of cabinets you want glass-smooth. Budget another $80 to $120 for a better gun and extra tips.
Which Magnum Are You Buying?
Graco sells four Magnums that look almost identical on a shelf, and half the listings call this one the Magnum TrueAirless X7. It is part 262805 either way — TrueAirless is the name for the RAC tip system, not a different pump. This review is the cart model.
Spec Sheet
- RETAIL NAMES
- Magnum X7 / Magnum TrueAirless X7 — same unit, part 262805
- MAX PRESSURE
- 3000 psi
- MAX FLOW
- 0.31 gal/min
- MOTOR
- 5/8 hp universal, standard 120V household outlet
- TIP RANGE
- 0.009 to 0.017-inch; ships with one 515 RAC tip
- HOSE
- 25-foot DuraFlex included; runs up to 100 feet
- PUMP
- Hardened stainless steel piston
- WEIGHT
- Roughly 34 lb as sold on the cart
- DUTY RATING
- About 125 gallons a year; Graco calls it ideal for projects up to 15 gallons per outing
- COATINGS
- Most unthinned latex, acrylic, primer, and stain; non-flammable oil-based OK; no lacquer
- WARRANTY
- 1 year from purchase, registered at graco.com
- PRICE
- $379–500 street; about $379 at Home Depot and Lowe's
Setup, First Spray, and the Flush You Cannot Skip
Out of the box to paint on the wall is about ten minutes, and the routine barely changes job to job. Drop the suction tube straight into a 1-gallon or 5-gallon pail, straining the paint on the way in if the can has been opened before. Hit PushPrime until you see steady paint with no bubbles. Bring pressure up from the bottom, not down from max, and stop the moment the fan edges quit tailing — anything past that is wasted paint and extra pump wear. Then the part people skip: for water-based coatings, screw the PowerFlush adapter onto a garden hose and push water through the pump, hose, and gun. Fifteen to twenty minutes, every time. Oil-based work skips the hose and flushes with mineral spirits instead. Skip the flush once and dried paint seizes the pump. Register the unit at graco.com when you unbox it, because the one-year warranty is written for a machine set up and run per the manual, which in practice makes the flush your warranty as much as your maintenance.
When It Goes Wrong — and How to Fix It
The tip fouls far more often a few days into a big exterior
Why it happens: It is almost always debris, not the machine. Dried skin off the top of an opened can, or grit off a pressure-washed wall that got back into the pail, works its way to the tip.
The fix: Rubber-band a $5 mesh strainer bag over the suction tube and strain the paint on the way into the pail. Then the 25-mesh inlet filter stops being your last line of defense. Clear the clog itself with a quarter-turn of the RAC tip — trigger it backward, flip it, keep spraying.
The stock gun and single tip fight you
Why it happens: Graco put a good pump behind an SG2 gun with a plastic trigger and grip and exactly one 515 tip in the box. That is a 0.015-inch orifice and a 10-inch fan, a general-purpose latex size and nothing else. The trigger pull is stiff and the fan is wider than you want for fine work.
The fix: Budget another $80 to $120 for a better gun and a couple of tips. Go 411 or 413 for stains and finer work, 517 for heavy exterior acrylics. Most people who keep the X7 make this upgrade anyway, so buy the kit that includes the extras if the price is close.
Sprayed siding flashes under raking light
Why it happens: Spraying lays a fast even film but leaves the paint sitting on top of the grain instead of worked into it. On rough cedar, stucco, and fences that reads as a sprayed-on look the first time the sun rakes across it.
The fix: Back-roll the wet coat on exterior siding, rough cedar, stucco, and fences. Spray a section, roll it out while it is still wet, move on. On smooth interior drywall you can skip the back-roll entirely.
The pail hook will not hold your can
Why it happens: The hook on the front of the cart takes a standard gallon, but the thicker molded handles on some 1-gallon and most 5-gallon cans do not seat in it.
The fix: Set the pail on the ground and drag it along with the cart, which is what most people end up doing. On a long wall it is easier to park the cart, run the hose, and leave the pail where it sits.
It is loud enough to leave your ears ringing
Why it happens: The pump hammers at full pressure, and a full day on a fence line adds up. This is the complaint that shows up over and over in owner reviews and it is fair.
The fix: Wear hearing protection, run the lowest pressure that still atomizes cleanly, and warn the neighbors before you start at 7 a.m.
Application Settings That Work
- AIRLESS
- Prime with PushPrime until the paint runs steady and bubble-free, then bring pressure up from the bottom until the fan edges stop tailing and stop there. The 515 tip in the box is the general-purpose latex size; go 411 or 413 for stains and fine work and 517 for heavy exterior acrylic. Tip range runs 0.009 to 0.017-inch. Add hose up to 100 feet for a second story and leave the cart parked at the bottom.
- THINNING
- None for standard interior and exterior latex — the whole point of 3000 psi is that you spray it as it comes from the can. Thick block fillers and elastomerics push it past its range and want a bigger gas or commercial pump. Non-flammable oil-based paints and stains are fine, but flush with mineral spirits instead of the garden hose. Lacquer and flammable solvent-borne coatings are prohibited in this unit and there is no conversion kit.
Magnum X7 vs Magnum X5 vs Magnum ProX17
All three are Magnums, all three spray unthinned latex, and the spec that decides between them is not the finish. It is tip ceiling, hose reach, and how many gallons a year the pump is built to survive.
| Magnum X7 | Magnum X5 | Magnum ProX17 | |
|---|---|---|---|
| Max tip size | 0.017-inch | 0.015-inch | 0.017-inch |
| Flow | 0.31 gal/min | 0.27 gal/min | 0.34 gal/min |
| Hose included / max | 25-foot / 100 feet | 25-foot / 75 feet | 50-foot / 150 feet |
| Annual rating | About 125 gallons | About 125 gallons | About 300 gallons |
| Frame | Wheeled cart, roughly 34 lb | Stand-mount, no wheels | Cart (17G178) or stand (17G177) |
| Gun | SG2, metal body with a plastic trigger and grip | Homeowner gun | Metal RAC-style with reversible SwitchTip |
| Street price | $379–500, about $379 at the big boxes | $299–399 | $700–850 |
| Where it wins | Whole-house DIY exteriors, fences, decks, one machine for inside and out | Interior walls and lighter coatings on a smaller budget | Frequent spraying, rentals, side jobs, and a pump you rebuild instead of replace |
One house, inside and out, every few years: the X7 is the Magnum most homeowners actually need, and the 0.017-inch tip plus the cart are what separate it from the X5. Interior walls only, on a tighter budget: the X5 and keep the difference. Spraying more than a house worth of paint a year, or taking money for it: the ProX17, because its pump is rated for the volume and the X7's is not.
What It's Good At
- +Spraying unthinned exterior acrylic and wall paint straight from a 5-gallon bucket without starving
- +Turning a two-to-three-day brush-and-roll exterior into an afternoon
- +Both faces of a 6-foot privacy fence in the time it takes to cut in one panel by hand
- +Rolling instead of carrying, with up to 100 feet of hose so you work a whole wall off one position
- +Tip flexibility from thin stain to heavy exterior latex on the same machine
- +Clearing a clog with a quarter-turn of the RAC tip instead of a teardown
- +Holding resale value, which a no-name airless does not
What It's Not Good At
- −Surviving contractor volume — the 125-gallon-a-year rating is not a suggestion
- −The stock SG2 gun, with a plastic trigger and grip and one 515 tip in the box
- −Cleanup, which is a 15-to-20-minute PowerFlush after every single job
- −Glass-smooth kitchen cabinets out of the box
- −Noise — at full pressure it will leave your ears ringing after a day on a fence line
- −Holding a thick-handled 1-gallon or 5-gallon can on the pail hook
- −Staying clog-free on a long exterior unless you strain the paint every time
Honest Alternatives
Wagner's homeowner airless undercuts the X7 by roughly $100 and runs high-efficiency airless that cuts the overspray cloud. A fine fence-and-shed machine. The trade-off is a smaller tip ceiling and a pump that does not push heavy exterior coatings the way the Graco stainless piston does.
Same family, more machine: 300 gallons a year against the X7's 125, a 150-foot hose, and a pump that survives the volume that wears an X7 out. If you will spray multiple houses a year or ease into light pro work, the extra $150 to $200 buys real longevity.
For punch-list work, a fence section, or shutters and trim, a handheld skips the hose-and-cart setup entirely. It will not spray a whole exterior on one cup and it is not built for big square footage, but for small scattered jobs it beats wheeling out the X7.
Magnum X7 Questions, Answered
Can the Magnum X7 spray unthinned latex paint?
Yes. The 3000-psi stainless piston pump atomizes unthinned wall and exterior latex without watering it down. Thick block fillers and elastomerics push it past its range and want a bigger gas or commercial pump. For standard interior and exterior latex straight from the can, it handles it.
What is the difference between the X5 and the X7?
The X7 takes a 0.017-inch tip versus the X5's 0.015, flows 0.31 gal/min versus 0.27, and runs a 100-foot hose versus 75. Both are rated 125 gallons a year. Buy the X7 for heavier exterior coatings or a long hose run around a house. The X5 is fine for interior walls only.
What does TrueAirless mean on the Magnum X7?
It is Graco's name for the X7's tip system, which is why retailers list it as the Magnum TrueAirless X7. The RAC reversible tip design softens the edges of the spray fan, so passes blend with less striping and edge overspray, and a quarter-turn of the tip clears a clog without a teardown. Same machine, part 262805, whether the listing says X7 or TrueAirless X7.
How many gallons can I run through it before it wears out?
Graco rates it for about 125 gallons a year. That is the homeowner-duty number. For a house or two a year it lasts years. Run a few hundred gallons through it like a contractor and the packings, seals, and pump wear out early — I have watched people buy an X7 to start a side business and burn it down in a season.
Does the Magnum X7 need an air compressor?
No. Airless means exactly that. A 5/8 hp electric motor drives a piston pump that pressurizes the paint itself to 3000 psi, and the tip atomizes it with no air supply. Plug it into a standard 120V outlet and it is self-contained.
Do I still need to back-roll after spraying?
On exterior siding, often yes. Spraying lays the film fast and even, but back-rolling the wet coat works the paint into the grain and kills the sprayed-on look that flashes under raking light. On smooth interior drywall you can skip it. On rough cedar, stucco, or a fence, back-roll.
Can it spray oil-based paint or lacquer?
Oil-based paints and stains, yes, as long as the material is non-flammable, and you clean up with mineral spirits instead of the garden-hose PowerFlush. Lacquer, no. Flammable solvent-borne coatings are prohibited in this electric unit and Graco makes no lacquer conversion kit for it.
What tips fit the Magnum X7?
It accepts RAC tips from 0.009 up to 0.017-inch and ships with a 515 tip, a 0.015-inch orifice throwing roughly a 10-inch fan, which is the general-purpose latex size. Go 411 or 413 for stains and fine work, 517 for heavy exterior acrylics. The 0.017-inch ceiling is the spec that separates it from the X5.
Which X7 part number should I buy?
Three come up side by side. 262805 is the base cart unit with the gun, 515 tip, 25-foot hose, and PowerFlush adapter. 25M502 adds a 20-inch tip extension, which is the ladder tax for ceilings and second-story siding. 18F027 adds the extension plus a 50-foot hose and a TRU311 fine tip, and on a two-story exterior that is usually the better buy, because the 50-foot hose alone runs $40 to $60 separately.
How long is the warranty?
One year from date of purchase, covering a unit set up and operated per the manual. Register it at graco.com when you unbox it so the date is not a receipt hunt later. In practice that means the flush step is part of your warranty, not just your maintenance.
